CISCO CERTIFIED INTERNETWORK EXPERTS (R&S)

Exam Description

The CCIE lab exam is an eight-hour, hands-on exam which requires you to configure and troubleshoot a series of complex networks to given specifications. Knowledge of troubleshooting is an important skill and candidates are expected to diagnose and solve issues as part of the CCIE lab exam. You will not configure end-user systems, but are responsible for all devices residing in the network (hubs, etc.). Point values and testing criteria are provided. More detail is found on the Routing and Switching Lab Exam Blueprint and the list of Lab Equipment and IOS Versions.

Exam Topics

The following topics are general guidelines for the content likely to be included on the lab exam. However, other related topics may also appear on any specific delivery of the exam. In order to better reflect the contents of the exam and for clarity purposes, the guidelines below may change at any time without notice.

Exam Sections and Sub-task Objectives

1.00 Implement Layer 2 Technologies
1.10 Implement Spanning Tree Protocol (STP)

(a) 802.1d

(b) 802.1w

(c) 801.1s

(d) Loop guard

(e) Root guard

(f) Bridge protocol data unit (BPDU) guard

(g) Storm control

(h) Unicast flooding

(i) Port roles, failure propagation, and loop guard operation
1.20 Implement VLAN and VLAN Trunking Protocol (VTP)
1.30 Implement trunk and trunk protocols, EtherChannel, and load-balance
1.40 Implement Ethernet technologies

(a) Speed and duplex

(b) Ethernet, Fast Ethernet, and Gigabit Ethernet

(c) PPP over Ethernet   (PPPoE)
1.50 Implement Switched Port Analyzer (SPAN), Remote Switched Port Analyzer (RSPAN), and flow control
1.60 Implement Frame Relay

(a) Local Management Interface (LMI)

(b) Traffic shaping

(c) Full mesh

(d) Hub and spoke

(e) Discard eligible (DE)
1.70 Implement High-Level Data Link Control (HDLC) and PPP
2.00 Implement IPv4
2.10 Implement IP version 4 (IPv4) addressing, subnetting, and variable-length subnet masking (VLSM)
2.20 Implement IPv4  tunneling and Generic Routing Encapsulation (GRE)
2.30 Implement IPv4 RIP version 2 (RIPv2)
2.40 Implement IPv4 Open Shortest Path First (OSPF)

(a) Standard OSPF areas

(b) Stub area

(c) Totally stubby area

(d) Not-so-stubby-area (NSSA)

(e) Totally NSSA

(f) Link-state advertisement (LSA) types

(g) Adjacency on a point-to-point and on a multi-access network

(h) OSPF graceful restart
2.50 Implement IPv4 Enhanced Interior Gateway Routing Protocol (EIGRP)

(a) Best path

(b) Loop-free paths

(c) EIGRP operations when alternate loop-free paths are available,
              and when they are not available

(d) EIGRP queries

(e) Manual summarization and autosummarization

(f) EIGRP stubs
2.60 Implement IPv4 Border Gateway Protocol (BGP)

(a) Next hop

(b) Peering

(c) Internal Border Gateway Protocol (IBGP) and External Border Gateway Protocol (EBGP)
2.70 Implement policy   routing
2.80 Implement Performance Routing (PfR) and Cisco Optimized Edge Routing (OER)
2.90 Implement filtering, route redistribution, summarization, synchronization, attributes, and other Advancedd features
3.00 Implement IPv6
3.10 Implement IP version 6 (IPv6) addressing and different addressing types
3.20 Implement IPv6 neighbor discovery
3.30 Implement basic IPv6 functionality protocols
3.40 Implement tunneling techniques
3.50 Implement OSPF version 3 (OSPFv3)
3.60 Implement EIGRP version 6 (EIGRPv6)
3.70 Implement filtering and route redistribution
4.00 Implement MPLS Layer 3 VPNs
4.10 Implement Multiprotocol Label Switching (MPLS)
4.20 Implement Layer 3 virtual private networks (VPNs) on provider edge (PE), provider (P), and customer edge (CE) routers
4.30 Implement virtual routing and forwarding (VRF) and Multi-VRF Customer Edge (VRF-Lite)
5.00 Implement IP Multicast
5.10 Implement Protocol Independent Multicast (PIM) sparse mode
5.20 Implement Multicast Source Discovery Protocol (MSDP)
5.30 Implement interdomain multicast routing
5.40 Implement PIM Auto-Rendezvous Point (Auto-RP), unicast rendezvous point (RP), and bootstrap router (BSR)
5.40 Implement multicast tools, features, and source-specific multicast
5.50 Implement PIM Auto-Rendezvous Point (Auto-RP), unicast rendezvous point (RP), and bootstrap router (BSR)
5.60 Implement IPv6 multicast, PIM, and related multicast protocols, such as Multicast Listener Discovery (MLD)
6.00 Implement Network   Security
6.01 Implement access   lists
6.02 Implement Zone Based   Firewall
6.03 Implement Unicast   Reverse Path Forwarding (uRPF)
6.04 Implement IP Source Guard
6.05 Implement authentication, authorization, and accounting (AAA) (configuring the AAA server is not required, only the client-side (IOS) is configured)
6.06 Implement Control Plane Policing (CoPP)
6.07 Implement Cisco IOS Firewall
6.08 Implement Cisco IOS Intrusion Prevention System (IPS)
6.09 Implement Secure Shell (SSH)
6.10 Implement 802.1x
6.11 Implement NAT
6.12 Implement routing protocol authentication
6.13 Implement device access control
6.14 Implement security features
7.00 Implement Network Services
7.10 Implement Hot Standby Router Protocol (HSRP)
7.20 Implement Gateway Load Balancing Protocol (GLBP)
7.30 Implement Virtual Router Redundancy Protocol (VRRP)
7.40 Implement Network Time Protocol (NTP)
7.50 Implement DHCP
7.60 Implement Web Cache Communication Protocol (WCCP)
8.0 Implement Quality of  Service (QoS)
8.10 (a) Network-Based Application Recognition (NBAR)
(b) Class-based weighted fair queuing (CBWFQ),  modified deficit round robin (MDRR),  and low latency queuing (LLQ)
(c) Classification
(d) Policing
(e) Shaping
(f) Marking
(g) Weighted random early detection (WRED) and random early detection (RED)
(h) Compression
8.20 Implement Layer 2 QoS: weighted round robin (WRR), shaped round robin (SRR), and policies
8.30 Implement link fragmentation and interleaving (LFI) for Frame Relay
8.40 Implement generic traffic shaping
8.50 Implement Resource Reservation Protocol (RSVP)
8.60 Implement Cisco AutoQoS
9.00 Troubleshoot a Network
9.10 Troubleshoot complex Layer 2 network issues
9.20 Troubleshoot complex Layer 3 network issues
9.30 Troubleshoot a network in response to application problems
9.40 Troubleshoot network services
9.50 Troubleshoot network security
10.00 Optimize the Network
10.01 Implement syslog and local logging
10.02 Implement IP Service Level Agreement SLA
10.03 Implement NetFlow
10.04 Implement SPAN, RSPAN, and router IP traffic export (RITE)
10.05 Implement Simple Network Management Protocol (SNMP)
10.06 Implement Cisco IOS Embedded Event Manager (EEM)
10.07 Implement Remote Monitoring (RMON)
10.08 Implement FTP
10.09 Implement TFTP
10.10 Implement TFTP server   on router
10.11 Implement Secure Copy Protocol (SCP)
10.12 Implement HTTP and   HTTPS
10.13 Implement Telnet
11.00 Evaluate proposed changes to a Network
11.01 Evaluate interoperability of proposed technologies against deployed technologies
(a) Changes to routing protocol parameters
(b) Migrate parts of a network to IPv6
(c) Routing Protocol migration
(d) Adding multicast supports
(e) Migrate spanning tree protocol
(f) Evaluate impact of new traffic on existing QoS design
11.02 Determine operational impact of proposed changes to an existing network
(a) Downtime of network or portions of network
(b) Performance degradation
(c) Introducing security breaches
11.03 Suggest Alternative solutions when incompatible changes are proposed to an existing network
(a) Introducing security breaches
(b) Topology shifts
(c) Reconfigurations
